HFS (R) SS 304 Condensing Coil - 1/2" Diameter with 1/2" NPT

HFSSKU: EXA-TANK12X36-COIL-0102

Price:
$2,000

Description

Features: Vessel
Material: Stainless Steel
Tri Clamp Lid Size (IN): 6
Liquid Line Connection (IN): MNPT 1/2
Vapor Line Connection (IN):  2x MNPT 1/2
Other Connections (IN): FNPT 1/4
Dual Bolt Clamp Size (IN): 6
Viton Gasket Size (IN): 6
Safety-Ring Size (IN): 14
Wall Density (MM): 5
Max Temp. (F): 250
Max Pressure (PSI): 150
Jacket Connection Type (IN): FNPT 1/2
Jacket OD (IN): 14
Jacket Length (IN): 33.5
Features: Coil
Material: Stainless Steel
Connection (IN): MNPT 1/2
Footprint Height (IN): 34
Footprint Diameter (IN): 6
Coil Count: 23
Tube ID (IN): 0.375
Single Coil Length (IN): 18.84
Overall Coil Length (IN):  433.32
Max Temp. (F): 250
Max Pressure (PSI): 100

Specifications: Vessel
Diameter (IN): 12
Height (IN): 36
Radius (IN): 6
Volume (Cu In): 4069.44
Fluid Capacity (L): 66.62
Fluid Capacity (Gal): 17.63
Butane Capacity (LBS): 72.00 - 90.00
Propane Capacity (LBS): 57.00 - 71.25
Biomass Capacity (LBS): 21.00 - 30.00
3A Sieve Capacity (LBS): 120.00
Nugget Ice Capacity (LBS): 96.00
Specifications: Jacket
Fluid Capacity (L): 20.54
Fluid Capacity (Gal): 5.43
Sleeve Ice Capacity (LBS): 29.59
Specifications: Coil
Diameter (IN): 0.375
Height (IN): 433.32
Radius (IN): 0.1875
Volume (Cu In): 47.83
Fluid Capacity (L): 0.78
Fluid Capacity (Gal): 0.21
Butane Capacity (LBS): 0.85 - 1.06
Propane Capacity (LBS): 0.67 - 0.84
